Rear bumper removal

2003 - 2009, roadster, coupe, facelift

Rear bumper removal

Postby decio - Mon Mar 01, 2010 9:33 am

Hi folks! Anyone knows how to remove rear bumper?! I already found a post about the removal of a front bumper, but I also need same advice for rear...I own a 3.0 si 2008. Thanks in advance!
User avatar
decio
Member
Member

Posts: 162
Joined: Fri Apr 03, 2009 1:35 pm
Location: Split
Country: Croatia (hr)

Re: Rear bumper removal

Postby cj10jeeper - Mon Mar 01, 2010 9:47 am

Similar process to the front:

Remove the fixings along the lower edge
Remove the clips under the rear wheel arches
detach clamps from where it joins the rear quarter panels
Pull it backward from the car taking care to disconnect the FM aerial that runs across left to right
Z4 3.0i SE Roadster (///M front, Red ///M leather seats, Aero sills, AE's, clear lenses, 4 spot rears, custom 108's, paddle shift/MFSW, quad exhaust, cf rear diffuser, Alutec strut bar, retrofit Bluetooth and a whole host of other mods subtle.)
User avatar
cj10jeeper
Moderator
Moderator

Posts: 14303
Joined: Fri Jun 22, 2007 11:50 am
Location: Lichfield, England
Country: United Kingdom (uk)

Re: Rear bumper removal

Postby decio - Mon Mar 01, 2010 10:21 am

Thanks alot! Must admit, the reply was really fast!
User avatar
decio
Member
Member

Posts: 162
Joined: Fri Apr 03, 2009 1:35 pm
Location: Split
Country: Croatia (hr)

Re: Rear bumper removal

Postby imp75 - Fri Jul 15, 2011 9:55 pm

Do the rear wheels have to come.off on order to get to fixings?
GONE - 2.0, sapphire black, alu trim, mods: msport seat transplant, 30mm drop, clear headlights, ZHP, OTH, strut brace, tinted tail lamps, carbon wrapped grilles and stubby
imp75
Senior Member
Senior Member

Posts: 2006
Joined: Thu Jan 13, 2011 11:17 pm
Location: Hartlepool
Country: United Kingdom (uk)

Re: Rear bumper removal

Postby cj10jeeper - Fri Jul 15, 2011 10:44 pm

imp75 wrote:Do the rear wheels have to come.off on order to get to fixings?

No
Z4 3.0i SE Roadster (///M front, Red ///M leather seats, Aero sills, AE's, clear lenses, 4 spot rears, custom 108's, paddle shift/MFSW, quad exhaust, cf rear diffuser, Alutec strut bar, retrofit Bluetooth and a whole host of other mods subtle.)
User avatar
cj10jeeper
Moderator
Moderator

Posts: 14303
Joined: Fri Jun 22, 2007 11:50 am
Location: Lichfield, England
Country: United Kingdom (uk)

Re: Rear bumper removal

Postby imp75 - Fri Jul 15, 2011 11:26 pm

thanks cj, im gonna have a go at taking mine off this weekend as i think one of the fixings has come loose.
GONE - 2.0, sapphire black, alu trim, mods: msport seat transplant, 30mm drop, clear headlights, ZHP, OTH, strut brace, tinted tail lamps, carbon wrapped grilles and stubby
imp75
Senior Member
Senior Member

Posts: 2006
Joined: Thu Jan 13, 2011 11:17 pm
Location: Hartlepool
Country: United Kingdom (uk)

Re: Rear bumper removal

Postby cj10jeeper - Sat Jul 16, 2011 9:45 am

imp75 wrote:thanks cj, im gonna have a go at taking mine off this weekend as i think one of the fixings has come loose.


Allow yourself a good 10 minutes to undo 5 self rapping bolts underneath, release the pins under each arch and unclip the corner fixings :)

Just remember the fm aerial and rear PFC harness as you pull the bumper away.
Z4 3.0i SE Roadster (///M front, Red ///M leather seats, Aero sills, AE's, clear lenses, 4 spot rears, custom 108's, paddle shift/MFSW, quad exhaust, cf rear diffuser, Alutec strut bar, retrofit Bluetooth and a whole host of other mods subtle.)
User avatar
cj10jeeper
Moderator
Moderator

Posts: 14303
Joined: Fri Jun 22, 2007 11:50 am
Location: Lichfield, England
Country: United Kingdom (uk)
